T8445                 T8465

制动鼓直径Drum Dia                180~450mm          180~650mm

制动盘直径Disc Dia                 102~400mm          102~520mm

工作行程Cutting Travel                190mm              265mm

主轴转速Spindle speed             30、52、85rpm       30、52、85rpm

进给速度Feed Speed                  0.1 6mm             0.16mm

主电机Main motor                    1.1 kw               1.1kw

外形尺寸Machine Size             1110*870*1000mm    1580x1020x1050mm

                                                     1880*1020*1970mm

包装尺寸Packing Size              900*820*1110mm     122020*1065*1110mm

带吊具With Lifting unit                                 1420*1065*1110mm

重量G.Weight/N.W                   350/290 kg           540/470kg
