整机特点
◆ 整台机器是按照高要求、高速度、高功率、可靠性及保障性而设计制造。快速换单、操作方便。
◆ 采用进口PLC、触摸屏多功能控制。可储存常用订单，加快换单操作。
◆ 选用优良材料及配件。
◆ 所有辊轴镀铬，增强硬度。
◆ 传动采用合金钢精细研磨齿轮、喷淋式循环润滑系统。
◆ 应用免键连续环，减少中间磨损，虚位放大，保持长期印刷套准。
◆ 采用挂版结构，自动复位、换单快捷。
◆ 各单元设置急停开关、防护操控保障。
◆ 间隙调整采用自锁式调整装置，操作方便。
◆ 电气元件、主关轴承、气动控制元件等采用国际品牌。
MACHINE FEATURES
◆ This machine is designed and produced based on high quality, high speed,high efficiency, reliability and safety, with the advantages of quick changing order and easy operation.
◆ Adapting imported PLC with touch screen control. It can save order, and accelerate the changing order speed.
◆ Adopt high quality material and assembly part.
◆ All cylinders and rollers are chrome plated for ideal hardness.
◆ Transmission gears from precision grinded alloy steel and with spraying type circulating lubrication system.
◆ Use expansion sets tight link to reduce abrasion of the shaft, keep high precision of the machine in long year.
◆ Adopt hanging structure, auto reset, quick changing order.
◆ Each unit is equipped with Emergency Stop switch to ensure safety operation.
◆ Using Self Locking gap adjustment device for ease operation.
◆ Electric element, bearing, and pneumatic element all use international famous brand.
| 型号/Modle | 1020 | 1224 | 1428 | 1630 | |
| 机械速度（张/分）Max.machine speed(pcs/m) | 220 | 180 | 160 | 140 | |
| 大进纸尺寸（mm） Max.feeding size | 1000×2200 | 1270×2600 | 1500×3000 | 1660×3200 | |
| 隔张送纸尺寸（mm） Skip.feeding size | 1250×2200 | 1500×2600 | 1800×3000 | 2000×3200 | |
| 大印刷面积（mm） Max.printing area | 950×2000 | 1200×2400 | 1430×2800 | 1600×3000 | |
| 小进纸尺寸（mm） Min.feeding size | 260×650 | 320×750 | 350×750 | 400×750 | |
| 大开槽深度（mm） Max.Depth of slotting | 250 | 320 | 390 | 430 | |
| 套色精度（mm） Registration precision |
≤±0.35（四色） (four colour) |
≤±0.4（四色）(four colour) |
≤±0.5（四色） (four colour) |
||
| 标准印版厚度（mm） Printing plate thickness | 7.2(含版衬) | ||||
| 有效进纸厚度(mm) Max.printing area | 2.5-9 | 2.5—12（10模切） | |||
|
小开槽间距（mm） Min.slotting interval |
正刀 Normal | 150×150×150×150 | |||
| 反刀 Reverse | 250×50×250×50 | 250×110×250×110 | |||
