Model
|
Nominal
Torque
|
Overrunning Limiting
Speed (r/min)
|
Dimension [mm]
|
Bearing
|
Weight
|
|
Outer race
|
Inner race
|
|
[N.m]
|
Inner
race
|
Outer
race
|
D[h7]
|
B
|
bwxtw
|
d[h7]
|
C
|
bnxtn
|
[kg]
|
|
CK-A1542
|
54
|
1750
|
500
|
42
|
23
|
3x1.8
|
15
|
24
|
3x1.4
|
6302
|
0.17
|
|
CK-A1747
|
75
|
1575
|
400
|
47
|
23
|
3x1.8
|
17
|
24
|
3x1.4
|
6304
|
0.21
|
|
CK-A2052
|
95
|
1400
|
400
|
52
|
23
|
3x1.8
|
20
|
24
|
3x1.4
|
6305
|
0.25
|
|
CK-A2562
|
145
|
1260
|
350
|
62
|
23
|
4x2.5
|
25
|
24
|
4x1.8
|
6306
|
0.35
|
|
CK-A3072
|
208
|
1050
|
300
|
72
|
23
|
5x3.0
|
30
|
24
|
5x2.3
|
6307
|
0.47
|
|
CK-A3580
|
340
|
815
|
200
|
80
|
28
|
8x4.0
|
35
|
30
|
6x2.8
|
6308
|
0.69
|
|
CK-A4090
|
462
|
700
|
200
|
90
|
28
|
8x4.0
|
40
|
30
|
6x2.8
|
6309
|
0.87
|
|
CK-A45100
|
783
|
560
|
200
|
100
|
28
|
8x4.0
|
45
|
30
|
6x2.8
|
6310
|
1.07
|
|
CK-A50110
|
850
|
525
|
180
|
110
|
28
|
10x5.0
|
50
|
30
|
8x3.3
|
6311
|
1.59
|
|
CK-A60130
|
1050
|
490
|
180
|
130
|
34
|
10x5.0
|
60
|
36
|
8x3.3
|
6312
|
2.16
|
|
CK-A65140
|
1224
|
490
|
180
|
140
|
34
|
10x5.0
|
65
|
36
|
10x3.3
|
6313
|
2.49
|
|
CK-A70150
|
1850
|
455
|
150
|
150
|
40
|
10x5.0
|
70
|
42
|
10x3.3
|
6314
|
3.36
|
|
CK-A75160
|
2140
|
455
|
150
|
160
|
40
|
12x5.0
|
75
|
42
|
12x3.3
|
6315
|
3.81
|
|
CK-A80170
|
2450
|
420
|
150
|
170
|
40
|
12x5.0
|
80
|
42
|
12x3.3
|
6316
|
4.29
|
|
CK-A1250
|
31.5
|
1750
|
400
|
50
|
22
|
3x1.8
|
12
|
24
|
3x1.4
|
|
0.24
|
|
CK-A1855
|
50
|
1575
|
350
|
55
|
22
|
4x2.5
|
18
|
24
|
4x1.8
|
|
0.28
|
|
CK-A2060
|
63
|
1600
|
350
|
60
|
22
|
6x3.5
|
20
|
24
|
6x2.8
|
|
0.33
|
|
CK-A2563
|
100
|
1260
|
350
|
63
|
24
|
6x3.5
|
25
|
26
|
6x2.8
|
|
0.37
|
|
CK-A2563T
|
140
|
1260
|
350
|
63
|
30
|
6x3.5
|
25
|
32
|
8x3.3
|
|
0.68
|
|
CK-A2870
|
180
|
1050
|
300
|
70
|
30
|
8x4.0
|
28
|
32
|
8x3.3
|
|
0.6
|
|
CK-A3080T
|
340
|
875
|
200
|
80
|
30
|
8x4.0
|
30
|
32
|
8x3.3
|
|
0.75
|
|
CK-A3585
|
400
|
815
|
200
|
85
|
30
|
8x4.0
|
35
|
32
|
8x3.3
|
|
1
|
|
CK-A35100
|
780
|
875
|
200
|
100
|
32
|
10x5.0
|
35
|
34
|
10x3.3
|
|
1.34
|
|
CK-A35140
|
1000
|
490
|
180
|
140
|
35
|
8x4.0
|
35
|
35
|
10x3.5
|
|
3.28
|
|
CK-A40100
|
780
|
560
|
200
|
100
|
34
|
10x5.0
|
40
|
34
|
10x3.3
|
|
1.2
|
|
CK-A40110
|
850
|
700
|
180
|
110
|
32
|
10x5.0
|
40
|
34
|
10x3.3
|
|
1.19
|
|
CK-A50125
|
1000
|
490
|
180
|
125
|
36
|
14x5.5
|
50
|
35
|
14x3.8
|
|
2.21
|
|
CK-A50130
|
1050
|
560
|
180
|
130
|
36
|
14x5.5
|
50
|
38
|
14x3.8
|
|
3.02
|
|
CK-A55160
|
2000
|
455
|
150
|
160
|
52
|
16x6.0
|
55
|
55
|
16x4.3
|
|
6.96
|
|
CK-A58130
|
1050
|
490
|
180
|
130
|
36
|
14x5.5
|
58
|
38
|
14x3.8
|
|
2.6
|
|
CK-A60180
|
2000
|
420
|
140
|
180
|
52
|
18x6.0
|
60
|
52
|
18x4.4
|
|
7.4
|
CK-A系列为无轴承支撑的楔块式单向离合器。径向尺寸与标准轴承尺寸相同。使用时需配合轴承安装，以承受轴向负载与径向负载。出厂时已加注润滑脂。
标准安装方式为CK-A型号与轴承同轴并排，相同的公差要求。内外环用键联接到轴和毂上。
该系列常用于提升机、输送机以及包装、印刷、食品、医疗、纺织、化工等机械设备上。

|
