参数Parameter

型号Model

UNIT

KSU-30G-Z.U

射出系统Injection unit

螺杆直径 Screw Diameter

mm

25

射出压力 Iniection Pressure

kg/cm2

1700

射出量 (PS)Max.Shot Weight(PS)

g

30

螺杆行程  Injection  Rate

mm

80

螺杆转数 Screw Speed Max.

Turn

0-215

射嘴行程 Nozzle  Retraction

mm

125

温度控制段数 Number of temperature Control

Snt

2/3

锁模系统Clamping unit

锁模力 Clamping Force

Tons

11

模板尺寸 Platen Size

mm

465*280

模柱间距 Distance Between Tie Bere

mm

280*150

最小模厚 Min.Mold Height

mm

40/80

开模行程 Openging Stroke

mm

200

最大开模距离 Max.  Open daylight

mm

240/280

顶出压力 Ejetor Force

Tons

1.3

动力电热系统Power\Heading unit

最大液压压力Max. Hydaulic Pressure

kg/cm2

140

泵浦吐出量 Pump  Outpet

1/min

23

马达电力 Pump  Motor  power

kw/HP

2.2/3HP

电热容量 Berrel  Heating  Power

kw

1.8

总用电量 Total Weight

kw

4.1

其他Other

机器重量 Machine  Weight

kg

890

机器外型尺寸Machine Dimensions(L*W*H)

m

1.3*0.9*1.8
