技术参数

Specifications

CK6166

床身最大工件直径

Max .Swing over bed

660mm

床身上最大工件长度

Max. Work piece Length

750/1000/1500/2000/3000mm

主轴孔锥度

Spindle taper

MT6(Φ90 1:20)

卡盘规格

Chuck size

C6 (D8)

主轴通孔直径

Thru-hole of spindle

52mm(80mm) 105mm

转速范围

Spindle speeds (12steps)

21-1620rpm(I 162-1620 II 66-660 III 21-210)

尾座**行程

Tailstock center sleeve travel

150mm

尾座套筒锥度

Tailstock center sleeve taper

MT5

重复定位精度

Repeatability error

0.01mm

快移速度

X/Z rapid traverse

3/6m/min

电机功率

Spindle motor

7.5kw

包装尺寸

Packing dimensions

(L×W×H mm)

Overall dimensions for 750

2440×1450×1700mm

Overall dimensions for 1000

2650×1450×1700mm

Overall dimensions for 1500

3150×1450×1700mm

Overall dimensions for 2000

3610×1450×1700mm

Overall dimensions for 3000

4610×1450×1700mm

重量

Weight(kg)

Length

毛重G.W.净重N.W.

Overall dimensions for 750

2300/2900

Overall dimensions for 1000

2450/3050

Overall dimensions for 1500

2650/3250

Overall dimensions for 2000

2880/3450

Overall dimensions for 3000

3700/4300
